User Manual MX Series Voice Gateway
40 New Rock Technologies, Inc.
Name
Description
Voice VLAN
VLAN to which the voice service (SIP signaling and RTP/T.38 media stream) belongs.
 None: disable the voice VLAN
 Mode 1: SIP and RTP/T.38 are on the same VLAN
 Mode 2: SIP and RTP/T.38 are on different VLANs
Management VLAN
 Selected: enable the management VLAN
 Deselected: disable the management VLAN
VLAN tag
Tag of the VLAN. The value ranges from 3 to 4093.
VLAN QoS
Priority of the VLAN. The value ranges from 0 to 7. A larger value indicates a higher priority of
a to-be-sent data packet.
IP address
assignment
Type for obtaining the IP address of the VLAN interface.
 Static: set the IP address to a static IP address
 DHCP: automatically obtain an IP address by using the DHCP protocol
IP address
IP address of the VLAN interface
Netmask
Subnet mask of the VLAN interface
Gateway IP address
IP address of the gateway of the VLAN interface
MTU
Maximum Transmission Unit value of the VLAN interface. The value ranges from 576 to 1500.
The default value is 1500.
 A reboot is required to enable the VLAN configuration.
 After a VLAN is configured, only PCs in the same VLAN can access the device.
 The device address used to log in to the Web GUI can be obtained by connecting a
phone to an FXS port of the device, and dialing ##. In the case of a single VLAN, the IP
address of the single VLAN is voiced; in the case of a multi-service VLAN, the IP address
of the management VLAN is voiced.
2.2.4 System
After login, click Basic>System to open the configuration interface.
