User Manual MX Series Voice Gateway
80 New Rock Technologies, Inc.
Name
Description
Domain name in
REGISTER
The default is Domain name.
Domain name: complete domain name used for registration (for example:
8801@registrar.newrock.com);
Sub domain name: only use the common part of the name of domain (for example:
Via field
Choose to use External network IP address (NAT public address) or LAN IP address as the Via
header field, the default is External network IP address.
To header field
Choose whether to use Sub domain name or Outbound proxy as the To header field, the default
is Sub domain name.
Call-ID header field
Choose whether to fill Call ID field with Host name or Local IP address, the default is Internal
network IP address.
Obtain Called party
number from
Choose whether the gateway acquires the called number from Request Line field or To field.
The default is from Request line field.
Calling party
number in call
transfer
Under call forwarding, the calling party number sent can be chosen from the originating number
or the forwarding number, the default is Forwarding number.
For example: the subscriber line 2551111 on the gateway activates call forwarding feature and
sets the destination to 3224422. When caller with 13055553333 calls 2551111, the call will be
forwarded to 3224422:
 If Originating number is chosen, the number 13055553333 will be sent to 3224422 as
calling party number;
 If Forwarding number is chosen, the number 2551111 will be sent to 3224422 as calling
party number.
Do not validate Via
Set to ignore Via field, By default, Via is ignored.
Re-register on
INVITE failure
Set to activate registration of all trunks or only failed trunks upon timeout of INVITE message.
By default, it is disabled.
Selecting the
receiving port for
response
Select either the receiving port of proxy or the sending port of proxy.
Always honor proxy
If this is selected, the SIP messages will always go through the SIP proxy server configured on
Basic > SIP page.
IMS
IMS
Select either the IMS mode or the NGN mode.
Early media
Enable RFC5009. It is not enabled by default.
Media direction
attribute
Set parameter values of the P-Early-Media header field:
 Supported
 Sendrecv
 Sendonly
 Recvonly
 Inactive
The fields vary according to the type of SIP message. They should be set as required by the peer
end.
Note: This parameter can be configured after Early media is selected.
Nextnonce
Select to carry “nextnonce” in 200 OK message or ignore “nextnonce”.
Registration
subscription
Select to subscribe registration status.
Multi port
A local SIP port can be assigned to each line.
SIP timer
Timer A
INVITE request retransmit interval, for UDP only. It is 1000 ms by default.
Timer B
INVITE transaction timeout timer. It is 16000 ms by default.
Timer D
Wait time for response retransmits. It is 16000 ms by default.
