Nice Linear LNVR1-08P - Rear View

11
Smart Surveillance
1 PoE ports # 1 to 16 (LNVR1-16P) 6 Audio OUT
2 RJ45 port - GbE uplink 7 VGA
3 HDMI 8 DI/DO terminal block
4 USB 3�0 port 9 Power socket (110/240V AC), w/ a power
5 Audio IN
The total PoE power budget for the LNVR1-08P’s 8 PoE ports is 120W�
The total PoE budget for the LNVR1-16P’s 16 PoE ports is 200W� Every 8 ports (#1 ~ #8 or #9 ~ #16)
provides 100W�
The total PoE power per port is 30w not to exceed total PoE power budget�
Please ensure the camera PD specication meet the NVR PSE power supply specication before
installation�
It is important to leave a clearance of 25cm behind the chassis� The clearance is required to
ensure an adequate airow through the chassis to ventilate heat�
To ensure normal operation, maintain ambient airow� Do not block the airow around chassis
such as placing the system in a closed cabinet�
25cm
Rear View
1
276
43589
IMPORTANT:
IMPORTANT:
