16
Rack-mounting
x4
If you need to install the NVR system into a rack cabinet:
1� Remove the foot pads from underneath the chassis�
2� Secure the brackets to the sides of the chassis by driving three (3) included screws�
If you have either a round-holed or square-holed rack, install cage nuts or clip
nuts to the desired positions on the rack posts�
The instructions below are based on the installation to a 4-post equipment rack�
The slide rails apply to rack cabinet of a depth of 700 to 900mm� With two (2) hard
drives, the chassis can weigh up to 4kg�
IMPORTANT:
