34 Unidrive M Regen Design Guide
Issue Number: 4
Table 3-17 690 V (500 V to 690 V ±10 %) Regen filter components to support up to 8 % THD
v
on the grid
* Modify Rated Current (05.007) to match current rating of inductor.
Drive mode Regen inductor SFF inductor SFF capacitor
Heavy
Duty
Normal
Duty
mH Arms
Part
number
mH Arms
Part
number
Capacitor
combination
Capacitor
connection
Rated
voltage
Vac
CT part
number/
supplier
part
number
Max.
capacitor
current per
can @
50 °C
(Arms)
Fuse
rating
(A)
Cap
bank A
µF
Cap
bank B
µF
07600190 5.300 19 4401-0210
1.400
22 4401-1211
10
Not
fitted
Star
780
1610-8104
C20AQGR
5100AASK
15
6
07600240* 07600190* 4.600 22 4401-0211 6
07600290* 07600240* 3.800 27 4401-0212
36
4401-1213 8
07600380* 07600290* 2.800 36 4401-0213 4401-1213 8
07600440* 07600380* 2.400 43 4401-0214 1.200 43 4401-1214 10
07600540* 07600440 1.900 52 4401-0215 1.000 52 4401-1215 12
08600630
1.600 63 4401-0216 0.800 63 4401-1216
15 640
1610-8154
C20ALGR
5150AASK
20 16
07600540* 10 780
1610-8104
C20AQGR
5100AASK
15 20
08600860* 08600630* 1.200 85 4401-0217 0.600 85 4401-1217 22
550
1610-8224
C20AKGR
5220AASK
25 20
09601040*
1.000 100 4401-0218 0.510 100 4401-1218
33
1610-8334
C20AKGR
5330AASK
30 20
08600860* 22
1610-8224
C20AKGR
5220AASK
25 25
09601310*
0.810 125 4401-0219 0.400 125 4401-1219 47
1610-8474
C20AKGR
5470AASK
35
32
09601040 32
10601500*
0.700 144 4401-0220 0.350 144 4401-1220
22 22
1610-8224
C20AKGR
5220AASK
25 32
09601310* 47
Not
fitted
1610-8474
C20AKGR
5470AASK
35 32
10601780* 10601500* 0.600 168 4401-0221 0.300 168 4401-1221
22 33
1610-8224
C20AKGR
5220AASK
1610-8334
C20AKGR
5330AASK
25
32
10601780* 0.530 192 4401-0421 0.260 192 4401-1222 40
11602100 11602100 0.441 230 4401-0297
0.221 230 4401-0306
47 47
1610-8474
C20AKGR
5470AASK
35
50
11602380
0.441 230 4401-0297 50
11602380 0.361 281 4401-0298 0.181 281 4401-0307 63
11602630
0.441 230 4401-0297 0.221 230 4401-0306 50
11602630 0.361 281 4401-0298 0.181 281 4401-0307 63
