noax N11 - Steel S19 P Technical Data

User Manual N11
Technical data
Industrial PC
3085-US-2.4 www.noax.com Page 103 of 120
15.2.12 Device type Steel - S19P
General
Dimensions ( L x W x H ):
18.0 inches x 16.6 inches x 3.9 inches
(457 mm x 421 mm x 99.5 mm)
Weight (depending on setup):
approx. 24.3 lb (approx. 11.0 kg)
Front:
Strengthened 0.16 inch (4 mm) cover glass
Stainless steel V2A (1.4301)
Housing:
Stainless steel V2A (1.4301)
Touchscreen:
Projected capacitive touchscreen
Power supply requirements
Rated input voltage:
+24 V DC (direct current)
Input voltage range:
18 V to 30 V DC (direct current)
Input current:
Max. 5.0 A
Power supply requirements with option “Internal power supply”
Rated input voltage:
95 V to 240 V AC (alternating current)
Nominal frequency range:
47 – 63 Hz
Max. input current:
2.0 A
Display (48.3 cm / 19 inches – SXGA)
Size / Type:
48.3 cm / 19 inches / TFT
Resolution:
SXGA 1280 x 1024
Viewable color depth:
24 Bit
Brightness:
Typ. 350 cd/m
2
IP protection class as per DIN EN 60529
Housing protection class
Variant “Production”
IP65 (NEMA 4) (with suitable connector protection)
Housing protection class
Variant “Hygienic (IP65)”
IP65 (NEMA 4) (with suitable connector protection)
Housing protection class
Variant “Hygienic (IP69k)”
IP69k (with suitable connector protection)
Ambient temperature
Start‐up temperature:
32°F to 104°F (0°C to +40°C)
Operating temperature:
23°F to 104°F (-5°C to +40°C)
Ambient temperature with option “Extended neg. temperature range (14°F / ‐10°C)”
Start‐up temperature:
14°F to 104°F (-10°C to +40°C)
Operating temperature:
5°F to 104°F (-15°C to +40°C)
Ambient temperature with option “Extended neg. temperature range (‐22°F / ‐30°C)”
Start‐up temperature:
-22°F to 104°F (-30°C to +40°C)
Operating temperature:
-22°F to 104°F (-30°C to +40°C)
