noax N11 - Steel S15 Technical Data

User Manual N11
Technical data
Industrial PC
3085-US-2.4 www.noax.com Page 97 of 120
15.2.6 Device type Steel - S15
General
Dimensions ( L x W x H ):
16.7 inches x 12.3 inches x 3.9 inches
(424 mm x 313 mm x 98 mm)
Weight (depending on setup):
approx. 18.7 lb (approx. 8.5 kg)
Front and housing:
Stainless steel V2A (1.4301)
Touchscreen:
Analog resistive touchscreen
Power supply requirements
Rated input voltage:
+24 V DC (direct current)
Input voltage range:
18 V to 30 V DC (direct current)
Input current:
Max. 5.0 A
Power supply requirements with option “Internal power supply”
Rated input voltage:
95 V to 240 V AC (alternating current)
Nominal frequency range:
47 – 63 Hz
Max. input current:
2.0 A
Display (38.1 cm / 15 inches – XGA)
Size / Type:
38.1 cm / 15 inches / TFT
Resolution:
XGA 1024 x 768
Viewable color depth:
24 Bit
Brightness:
Typ. 400 cd/m
2
IP protection class as per DIN EN 60529
Housing protection class
IP65 (NEMA 4) (with suitable connector protection)
Ambient temperature
Start‐up temperature:
32°F to 104°F (0°C to +40°C)
Operating temperature:
23°F to 104°F (-5°C to +40°C)
Ambient temperature with option “Extended pos. temperature range”
Start‐up temperature:
32°F to 122°F (0°C to +50°C)
Operating temperature:
23°F to 122°F (-5°C to +50°C)
Ambient temperature with option “Extended neg. temperature range (14°F / ‐10°C)”
Start‐up temperature:
14°F to 104°F (-10°C to +40°C)
Operating temperature:
5°F to 104°F (-15°C to +40°C)
Ambient temperature with option “Extended temperature range”
Start‐up temperature:
-22°F to 122°F (-30°C to +50°C)
Operating temperature:
-22°F to 122°F (-30°C to +50°C)
