noax N11 - LED Indicator Area Details; Key Area Functions; Configurable Function Keys F1-F3

User Manual N11
Operation
Industrial PC
www.noax.comPage 60 of 120 3085-US-2.4
10.2.3
LED area
LED
Function
OK (green)
OK LED
D Lights up when the Industrial PC is operational. All of the parame
ters monitored by the MCU are within the limits. (see section 11.1
.)
D Flashes in standby mode.
! (red)
Error LED
D Lights up when an error or a critical event occurs with the
Industrial PC hardware.
D Flashes when the IPC is in temperature limiting mode.
(yellow/red)
Input LED / HDD LED
D Lights up yellow when a valid input is made (has priority).
D Lights up red when there is hard disk activity.
(blue)
Power LED
D Lights up when the Industrial PC is turned on.
When the Error LED starts to light up continuously, the other LEDs will no longer have
their normal function and will instead display an error code. Possible LED states are
“off”, “slow flashing”, “fast flashing”, and “on” (see Chapter 14).
10.2.4 Key area
Key
Function
- (Minus)
D Reduces display brightness.
+ (Plus)
D Increases display brightness.
(On/Off)
D Switches the Industrial PC on/off and wakes it up from standby.
D Switches the display backlight on/off.
D Initiates a hard reset or software shutdown.
10.2.5 Function keys F1 to F3
The function keys F1 to F3 are freely configurable by the user.
The nSMART™ software can be used to assign the keys.
The keys are not assigned in the factory default settings.
See Chapter 11.5 for a detailed explanation of how to assign the function keys.
