noax N11 - Steel S19 Technical Data

User Manual N11
Technical data
Industrial PC
3085-US-2.4 www.noax.com Page 99 of 120
15.2.8 Device type Steel - S19
General
Dimensions ( L x W x H ):
19.6 inches x 17.2 inches x 5.4 inches
(498 mm x 438 mm x 136 mm)
Weight (depending on setup):
approx. 47.4 lb (approx. 21.5 kg)
Front and housing:
Stainless steel V2A (1.4301)
Touchscreen:
Analog resistive touchscreen
Power supply requirements
Rated input voltage:
100 V to 236 V AC (alternating current)
Nominal frequency range:
47 – 63 Hz
Max. input current:
2.0 A
Power supply requirements with option “Without internal power supply”
Rated input voltage:
+24 V DC (direct current)
Input voltage range:
18 V to 30 V DC (direct current)
Input current:
Max. 5.0 A
Display (48.3 cm / 19 inches – SXGA)
Size / Type:
48.3 cm / 19 inches / TFT
Resolution:
SXGA 1280 x 1024
Viewable color depth:
24 Bit
Brightness:
Typ. 350 cd/m
2
IP protection class as per DIN EN 60529
Housing protection class
IP69k (with suitable connector protection)
Ambient temperature
Start‐up temperature:
32°F to 104°F (0°C to +40°C)
Operating temperature:
23°F to 104°F (-5°C to +40°C)
Ambient temperature with option “Extended pos. temperature range”
Start‐up temperature:
32°F to 122°F (0°C to +50°C)
Operating temperature:
23°F to 122°F (-5°C to +50°C)
Ambient temperature with option “Extended neg. temperature range (14°F / ‐10°C)”
Start‐up temperature:
14°F to 104°F (-10°C to +40°C)
Operating temperature:
5°F to 104°F (-15°C to +40°C)
Ambient temperature with option “Extended temperature range”
Start‐up temperature:
-22°F to 122°F (-30°C to +50°C)
Operating temperature:
-22°F to 122°F (-30°C to +50°C)
