noax N11 - Compact C21 W Technical Data

User Manual N11
Technical data
Industrial PC
3085-US-2.4 www.noax.com Page 95 of 120
15.2.4 Device type Compact - C21W
General
Dimensions ( L x W x H ):
21.6 inches x 14.0 inches x 4.6 inches
(549 mm x 356 mm x 117 mm)
Weight (depending on setup):
approx. 24.9 lb (approx. 11.3 kg)
Front:
Plastic, with paint finish
Housing:
Aluminum, with structure paint finish
Touchscreen:
Analog resistive touchscreen
Power supply requirements
Rated input voltage:
+24 V DC (direct current)
Input voltage range:
18 V to 30 V DC (direct current)
Input current:
Max. 5.0 A
Power supply requirements with option “Internal power supply”
Rated input voltage:
100 V to 120 V / 208 V to 240 V AC (alternating current)
Nominal frequency range:
47 – 63 Hz
Max. input current:
2.0 A
Display (57.2 cm / 21.5 inches – Full‐HD)
Size / Type:
57.2 cm / 21.5 inches / Widescreen TFT
Resolution:
Full‐HD 1920 x 1080
Viewable color depth:
24 Bit
Brightness:
Typ. 300 cd/m
2
IP protection class as per DIN EN 60529
Housing protection class
IP65 (NEMA 4) (with suitable connector protection)
Ambient temperature
Start‐up temperature:
32°F to 113°F (0°C to +45°C)
Operating temperature:
23°F to 113°F (-5°C to +45°C)
Ambient temperature with option “Extended neg. temperature range (14°F / ‐10°C)”
Start‐up temperature:
14°F to 113°F (-10°C to +45°C)
Operating temperature:
5°F to 113°F (-15°C to +45°C)
