noax N11 - Compact C12 and C12 P Technical Data

User Manual N11
Technical data
Industrial PC
www.noax.comPage 92 of 120 3085-US-2.4
15.2
Technical data on the Industrial PC variants
15.2.1 Device type Compact - C12 and C12P
General
Compact - C12
Compact - C12P
Dimensions ( L x W x H ):
12.6inch x 10.2inch x 3.4inch
318 mm x 258 mm x 86 mm
12.6inch x 10.2inch x 3.4inch
318 mm x 258 mm x 87 mm
Weight (depending on setup):
Approx. 9.9 lb
(Approx.4.5 kg)
Approx. 10.8 lb
(Approx.4.9 kg)
Front:
Plastic, with paint finish
Aluminum, with structure
paint finish
Enclosure:
Aluminum, with structure
paint finish
Aluminum, with structure
paint finish
Touchscreen:
Analog resistive
touchscreen
Projected capacitive
touchscreen
Power supply requirements
Rated input voltage:
+24 V DC (direct current)
Input voltage range:
18 V to 30 V DC (direct current)
Input current:
Max. 5.0 A
Display (30.7 cm / 12.1 inches – XGA)
Size / Type:
30.7 cm / 12.1 inches / TFT
Resolution:
XGA 1024 x 768
Viewable color depth:
24 Bit
Brightness:
Typ. 500 cd/m
2
IP protection class as per DIN EN 60529
Housing protection class
IP65 (NEMA 4) (with suitable connector protection)
Ambient temperature
Start‐up temperature:
32°F to 113°F (0°C to +45°C)
Operating temperature:
23°F to 113°F (-5°C to +45°C)
Ambient temperature with option “Extended pos. temperature range”
Start‐up temperature:
32°F to 131°F (0°C to +55°C)
Operating temperature:
23°F to 131°F (-5°C to +55°C)
Ambient temperature with option “Extended neg. temperature range (14°F / ‐10°C)”
Start‐up temperature:
14°F to 113°F (-10°C to +45°C)
Operating temperature:
5°F to 113°F (-15°C to +45°C)
Ambient temperature with option “Extended temperature range”
Start‐up temperature:
-22°F to 131°F (-30°C to +55°C)
Operating temperature:
-22°F to 131°F (-30°C to +55°C)
