15.6.1
Devices without internal power supply
This applies to device types C12, C12P, C15, C15P, C19, C21W,
S12, S15, P15, S15P, S15R, S19P, S19R, S21WP, S21WR as well as
S15‐G2 and S19 without internal power supply
The input fuse with the description “F2” is located on the mainboard in a socket with
protection cap near the power input plug.
Type of fuse:
Glass tube fuse, format 0.2 inches x 0.8 inches (5 x 20 mm),
characteristic 5 A / 250 V / “slow‐acting” behavior according to IEC 60127‐2.
15.6.2
Device type S15‐G2 and S19 as well as C15, C15P, C19,
C21W, S15P, S15R, S19P, S19R, S21WP, S21WR with option
“Internal power supply”
The holder for the two supply voltage fuses is located below the power cord connector.
To remove the fuse holder, push down the small black lever on it. Now the fuse holder
can be pulled out.
Type of fuse: 2 x glass tube fuse, format 0.2 inches x 0.8 inches (5 x 20 mm),
characteristic 2 A /250 V / “slow‐acting” behavior according to IEC 60127‐2.
15.6.3 Device type S15 with option “Internal power supply”
The holder for the supply voltage fuses is located in the connector area beside the
power cord connector.
To remove, use a flat‐head screwdriver to turn the holder insert a quarter turn.
Type of fuse: 1 x glass tube fuse, format 0.2 inches x 0.8 inches (5 x 20 mm),
characteristic 2 A / 250 V / “slow‐acting” behavior according to IEC 60127‐2.
