15.4
Technical data on the external power supplies
15.4.1 External power supply
General
Dimensions (L x W x H):
4.7 inches x 2.0 inches x 1.2 inches
(120 mm x 52 mm x 31 mm)
Weight:
approx. 1.1 lb (approx. 0.5 kg, incl. mounting bracket)
Housing:
Plastic (polycarbonate)
Conformity:
CE, FCC
Power supply requirements
Input voltage:
100 to 240 V AC (alternating current)
Input frequency:
47 – 63 Hz
Input current:
Max. 1.5 A
Output voltage:
+24 V stabilized
Output current:
Max. 3.0 A
Ambient temperature
Operation:
-4°F to 131°F (-20°C to +55°C)
Derating from 104°F (+40°C): -2.5% per °C
Storage and transportation:
-4°F to 176°F (-20°C to +80°C)
IP protection class as per DIN EN 60529
Housing protection class
IP40
15.4.2 External power supply IP65 (NEMA 4) (24 V)
General
Dimensions (L x W x H):
8.7 inches x 5.7 inches x 2.1 inches
(220 mm x 144 mm x 54 mm)
Weight:
approx. 1.1 lb (approx. 0.5 kg)
Housing:
Aluminum, with paint finish
Conformity:
CE, FCC
Power supply requirements
Input voltage:
100 to 240 V AC (alternating current)
Input frequency:
47 – 63 Hz
Input current:
Max. 1.4 A
Output voltage:
+24 V
Output current:
Max. 2.5 A
Ambient temperature
Operation:
-4°F to 122°F (-20°C to +50°C)
Storage and transportation:
-4°F to 176°F (-20°C to +80°C)
IP protection class as per DIN EN 60529
Housing protection class
IP65 (NEMA 4)
