noax N11 - Compact C15 and C15 P Technical Data

User Manual N11
Technical data
Industrial PC
3085-US-2.4 www.noax.com Page 93 of 120
15.2.2 Device type Compact - C15 and C15P
General
Compact - C15
Compact - C15P
Dimensions ( L x W x H ):
15.2inch x 12.8inch x 4.1inch
(387 mm x 325 mm x 104mm)
15.2inch x 12.8inch x 4.0inch
(387 mm x 325 mm x 101mm)
Weight (depending on setup):
Approx. 17.4 lb
(Approx. 7.9 kg)
Approx. 18.3 lb
(Approx. 8.3 kg)
Front:
Plastic, with paint finish
Aluminum, with structure
paint finish
Enclosure:
Aluminum, with structure
paint finish
Aluminum, with structure
paint finish
Touchscreen:
Analog resistive
touchscreen
Projected capacitive
touchscreen
Power supply requirements
Rated input voltage:
+24 V DC (direct current)
Input voltage range:
18 V to 30 V DC (direct current)
Input current:
Max. 5.0 A
Power supply requirements with option “Internal power supply”
Rated input voltage:
100 V to 120 V / 208 V to 240 V AC (alternating current)
Nominal frequency range:
47 - 63 Hz
Max. input current:
2.0 A
Display (38.1 cm / 15 inches – XGA)
Size / Type:
38.1 cm / 15 inches / TFT
Resolution:
XGA 1024 x 768
Viewable color depth:
24 Bit
Brightness:
Typ. 400 cd/m
2
IP protection class as per DIN EN 60529
Housing protection class
IP65 (NEMA 4) (with suitable connector protection)
Ambient temperature
Start‐up temperature:
32°F to 113°F (0°C to +45°C)
Operating temperature:
23°F to 113°F (-5°C to +45°C)
Ambient temperature with option “Extended pos. temperature range”
Start‐up temperature:
32°F to 131°F (0°C to +55°C)
Operating temperature:
23°F to 131°F (-5°C to +55°C)
Ambient temperature with option “Extended neg. temperature range (14°F / ‐10°C)”
Start‐up temperature:
14°F to 113°F (-10°C to +45°C)
Operating temperature:
5°F to 113°F (-15°C to +45°C)
Ambient temperature with option “Extended temperature range”
Start‐up temperature:
-22°F to 131°F (-30°C to +55°C)
Operating temperature:
-22°F to 131°F (-30°C to +55°C)
