User Manual N11
Installation
Industrial PC
3085-US-2.4 www.noax.com Page 41 of 120
8.8.3 VESA 100 mounting option
There are four threaded holes in the rear side of the Industrial PC as per
“VESA (FDMI™) standard” - variant VESA MIS‐D, 100, C.
(100 mm / 3.9 inches distance in a square, M6 thread, depth 7.5 mm / 0.3 inches)
In condition of delivery mounted screws only protect the threaded holes.
These screws are not suitable for mounting the device.
8.8.4
Side mounting options
The drill holes in the side of the housing rear cover are provided for the device mount
ing bracket. A range of accessory components can be mounted on these brackets.
Some accessory components for side mounting (optional) are listed below:
D noax Wall mount bracket for S15‐G2 and S19
D noax Table stand for S15‐G2 and S19
