noax N11 - Steel S21 WP Model; Steel S21 WR Model

To Next Page

To Previous Page

User Manual N11

Device types

Industrial PC

3085-US-2.4 www.noax.com Page 19 of 120

Industrial PC Steel - S21WP

Stainless steel enclosure

21.5 inch widescreen display

PCAP touchscreen

Industrial PC Steel - S21WR

Stainless steel enclosure

21.5 inch widescreen display

Resistive touchscreen
