MPLS Guide MPLS and RSVP-TE
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
237
Srlg Groups The shared risk link group (SRLG)
Interfaces The total number of interfaces
Transmitted The number of packets and octets transmitted from the interface
Received The number of packets and octets received
In Label The ingress label
In I/F The ingress interface
Out Label The egress label
Out I/F The egress interface
Next Hop The next-hop IP address for the static LSP
Type Indicates whether the label value is statically or dynamically
assigned
Invalid Labels — the number of incoming packets discarded due to
invalid labels
IPoMPLS Pkts — the number of incoming labeled packets
discarded due to invalid IP packet headers in the packet
Stack Too Big Pkts — the number of incoming packets discarded
due to having greater than the maximum number of labels in the
label stack (that is, greater than five)
TTL Expired Pkts — the number of incoming packets discarded
due to exceeding the maximum Time-To-Live (TTL) value
Other Discard Pkts — the number of incoming packets discarded
due to internal errors (for example, memory corruption or invalid
label table programming)
Last Invalid Label Value — the value of the last invalid label received
Label Position — the position in the label stack of the last invalid
label received
Table 11 Router MPLS Interface Field Descriptions (Continued)
Label Description
