PAGE 22 1010/2020 INSTALLATION AND PROGRAMMING MANUAL
COPYRIGHT © 2000, NOTIFIER INERTIA PTY LTD
under which each
ENTERING CUSTOM POINT LABELS
Custom point labels may be programmed by entering "0" from the initial program prompt.
ENTER 1 to 9 FOR 9 CUSTOM MESSAGES
OR 0 FOR CUSTOM POINT LABEL:
Select “0”
A second prompt will be displayed on the computer monitor.
LCD-80 set for 20-character labels:
ENTER 1 to 128 FOR CUSTOM POINT LABEL (20 CHARACTERS):
where 1-128 represent zones in the control panel.
Once a point number has been entered, the LCD-80 screen will display either the
custom zone message or the last stored point message. The label may be changed by backspacing
over the existing label and typing a new one.
Once the message has been changed or entered satisfactorily, press ENTER to store
the message. The LCD-80 screen will retain the previous point label information while
the monitor display will return to the 40-character custom label prompt:
ENTER 1 to 128 FOR CUSTOM POINT LABEL (40 CHARACTERS):
Continue to enter point label information or press ESC to return to the initial programming
prompt:
ENTER 1 to 9 FOR 9 CUSTOM MESSAGES OR 0 FOR CUSTOM POINT LABEL:
Once all programming of the LCD-80 has been completed, remove the Programming
Key.
See the next section for setting the switches for the LCD-80 in Programming Mode.
