PAGE 66 1010/2020 INSTALLATION AND PROGRAMMING MANUAL
COPYRIGHT © 2000, NOTIFIER INERTIA PTY LTD
OUTPUT MODULES
• These software types do have control-by-event programming capability.
Type ID Application Bell
Isolate
Break
Tabs
CMXC
CMXS
CON*
FORC*
FRCM
CMX FORM C
CMX
CONTROL
CONTROL
FORM C
RELAY
FORMC
MANUAL
CMX Control Module or an XP5-C
used as a Relay Output
CMX Control Module or an XP5-C
used as a Monitored Output
CMX Control Module or an XP5-C
used as a Monitored Output (Bell) or
a Sounder Base
CMX Control Module or an XP5-C
used as a
FORM-C Relay.
CMX Control Module or an XP5-C
used as a FORM-C Relay. This
device does not deactivate when a
system reset occurs. This module
can be used for fan control
applications where a latching plant trip
is required and can be mapped only to
an AFCM Annunciator point.
No
No
Yes
Yes
No
Yes
No
No
Yes
Yes
Note: Although each type ID listed above is prompted for Signal Silence during programming only
those CON and FORC will isolate by using the “EXT BELL ISOLATE” button.
SOFTWARE ZONES
Type I.D. Display Label Type of Device
FZON
RZON
FORWARD ZONE
REVERSE ZONE
A software-defined zone that is forward-
activating.
A software-defined zone that is reverse-
activating.
• A Forward-Activating Zone is a software zone, which once activated by an input device or
other forward zone may in turn activate other zones and/or output devices directly.
Zones and output devices activated by a forward zone have that forward zone contained in
their CBE List.
• A Reverse-Activating Zone is a software zone, which if not activated directly by an input
device or forward zone may be activated through an associated CBE equation. A Reverse
Zone may be referenced in other CBE Equations.
