PAGE 46 1010/2020 INSTALLATION AND PROGRAMMING MANUAL
COPYRIGHT © 2000, NOTIFIER INERTIA PTY LTD
LABEL (3=LBL)
Option 3 of the Partial Point Programming Menu allows the programmer to change the 20-Character
Custom Label (Descriptor) associated with each detector, module, or software zone in the system.
Acceptable characters for device or zone labels are as follows:
Letters A through Z, digits 0 through 9, periods (.), dashes (-), and spaces.
The following display illustrates renaming control module 21 on Loop 1.
Select 3 from the Partial Point Programming Sub Menu.
ENTER LXX(D/M)YY, ZXXX OR AXXPYY FOR PT CHANGE
(BCKSPC TO ABORT)
L1M21
ENTER 20 CHARACTER CUSTOM LABEL LEVEL 4 BELL OUTPUT
Programming Tip:
Creative use of the Label feature on both devices and zones allows the programmer to be extremely
specific in naming each device. For instance, for a group of Addressable devices congregated in a
particular area (such as a floor or a section of a building), map each device to the same software
zone and label the zone to serve as an additional 20 characters of information to the individual
device labels.
Make this software zone the first zone in the CBE of those detectors and it will appear on the display
whenever any of those detectors go into alarm. (You can also then use the ‘Global Zone Isolate’
function to isolate that group of detectors)
Ie: Make the detector descriptor “ROOM 212 BATHROOM”
And make the zone “LEVEL 2 APARTMENTS”
