1010/2020 INSTALLATION AND PROGRAMMING MANUAL PAGE 59
COPYRIGHT © 2000, NOTIFIER INERTIA PTY LTD
C.B.E SIZE LIMITATIONS
Each Control-By-Event has a physical size limitation of 14 bytes in control panel memory.
For initiating devices, the Control-By-Event size can be calculated by the following formula:
Size in bytes = 1 + (Number of Zones) + (Number of Control Modules X 3) +1
Example: The following Control-By-Event takes up 11 bytes in memory.
( Z1 Z6 Z12 L2M4 L7M15 )
Size in bytes 1 + ( 3 ) + ( 2 X 3 ) +(1) = 11
For output devices, the Control-By-Event size can be calculated by adding the components involved
using the following values:
( = 1 byte
) = 1 byte
OR( = 1 byte
AND( = 1 byte
NOT( = 1 byte
XZONE( = 1 byte
DEL( = 1 byte
TIM( = 1 byte
SDEL( = 1 byte
Zones = 1 byte each
Initiating devices = 3 bytes each
The time specifications for the DEL, TIM, and SDEL operators = 6 bytes
Examples:
1) The following Control-By-Event takes up 13 bytes in memory:
OR( Z1 Z4 Z9 Z16 Z23 LID3 L2M7 )
Size in bytes 1 + 1 + 1 + 1 + 1 + 1 + 3 + 3+ 1 = 13
2) The following CBE takes up 11 bytes in memory:
DEL( 00.00.30 00.01.30 or ( Z1 ) )
Size in bytes 1 + 6 + 1+1+1+1 = 11
Due to the 14-byte size limitation, it may be necessary to use more than one equation or list to
accomplish a desired result. Through the use of reverse activating zones, an equation, which
normally would contain too many bytes, can be broken up into several smaller equations.

Notifier 1010 Specifications

General

Operating Temperature	32°F to 120°F (0°C to 49°C)
Relative Humidity	10% to 93% non-condensing
Type	Fire Alarm Control Panel
Power Supply	120/240 VAC, 50/60 Hz
Battery Backup	Up to 18 Amp Hour Batteries
Communication Options	optional IP communicator, optional cellular communicator
Dimensions	14.5" H x 3.5" D
Compliance	UL 864
