1010/2020 INSTALLATION AND PROGRAMMING MANUAL PAGE 65
COPYRIGHT © 2000, NOTIFIER INERTIA PTY LTD
SYSTEM COMMON OUTPUT MODULES
• These software types cannot be programmed for Bell Isolate.
• These software types do not have any control-by-event programming.
Type I.D. Type of Device Break tabs
GAC
GAS
GTC
ISOC
ISOS
ACFC
ACFS
GN ALARM
FORC
GN ALARM SUP
GN TRBL FORC
GN ISOL FORC
GN ISOL SUP
AC FAIL FORC
AC FAIL SUP
CMX control module or an XP5-C used
as a Form-C Relay, for Common
Alarm.
CMX control module or an XP-5-C used
as a Monitored Output for Common
Alarm.
CMX control module or an XP5-C used
as a Form-C Relay, for Common
Fault.
CMX control module or an XP5-C used
as a Form-C Relay, for Common
Isolate.
CMX control module or an XP-5-C used
as a Monitored Output for Common
Isolate
CMX control module or an XP5-C used
as a Form-C Relay for Mains Fail.
CMX control module or an XP-5-C used
as a Monitored Output for Mains Fail
Yes
No
Yes
Yes
No
Yes
No
