PAGE 34 1010/2020 INSTALLATION AND PROGRAMMING MANUAL
COPYRIGHT © 2000, NOTIFIER INERTIA PTY LTD
SECTION TWO: PROGRAMMING
PROGRAMMING OVERVIEW
RECOMMENDED PROCEDURE
The 1010/2020 programmablility is extremely versatile. It can be programmed 4 ways.
1. Via the panel keypad on the DIA
2. Via a Laptop in terminal mode
3. Via a Laptop using the Notifier Verifire Program with full Upload & Download facility.
4. Via the NCS graphics system direct connected on the network.
For initial programming of the 2020 or 1010 the following procedure must be followed.
• Locate the Program Configuration work Sheets (Supplied by Notifier/Inertia Fire systems). Use
these Work Sheets to record the exact information for every detector, module, Annunciator point
and groups in the system.
1. Install all system boards.
2. Apply power to the control panel as described in the section one of Installation manual.
3. Perform a full system program from the DIA telling the system of all boards installed.
4. Re-power the system.
5. Then you may use a Laptop or NCS or the DIA to perform point installation.
Once system programming is complete it is strongly recommended you perform 3 steps.
1. Change the system password from that of the default supplied from the factory. This will prevent
unauthorised access to configuration information.
2. Make a hard-copy record of the program on the printer (If fitted).
3. Upload the program to a PC and save to disk.
OVERVIEW
The 1010/2020 programming is menu driven, simply choose which function you want and implement
it. This manual describes the basic functionality of the programming, assuming that the operator
has received programming training from Notifier Inertia fire Systems.
Programming is separated into two basic functions;
1. Full Programming,- allows you to install new devices, Annunciators and loop cards etc.
2. Partial programming,- allows you to change parameters of devices Annunciators and Loops etc.
Both functions can only be accessed via the Prog button and entering the password.
Important Note: This programming manual refers to the Software Release Version 3 AUS 1. Do not
attempt to use any Software Type ID’s described in this manual, on any Notifier
Inertia Product prior to this Version 3 software release. The software release
number can be found on the Eprom label on the CPU card.
