PAGE 56 1010/2020 INSTALLATION AND PROGRAMMING MANUAL

C.B.E EQUATIONS: OPERATORS

Operator: The first (and most useful) operator is OR.

Equation: OR(Z9 Z15 Z23)

If ANY one of the three operand’s in the equation

are in alarm, then the control module will be activated.

IF Software Zone 9 is in alarm OR

IF Software Zone 15 is in alarm OR

IF Software Zone 23 is in alarm,

THEN this control module will be activated.

AND

Operator: The AND operator requires that each operand be in alarm.

Equation: AND(Z9 Z15 Z23)

ALL three operand’s in the equation MUST be

in alarm for the control module to be activated.

IF Software Zone 9 is in alarm AND

IF Software Zone 15 is in alarm AND

IF Software Zone 23 is in alarm,

THEN this control module will be activated.

NOT

Operator: The NOT operator inverts the state of the operand (activated to deactivated OR

deactivated to activated).

Equation: NOT(Z2)

The control module will remain activated UNTIL

the operand comes into alarm.

IF Software Zone 2 is in alarm,

THEN this control module will be deactivated.
