1010/2020 INSTALLATION AND PROGRAMMING MANUAL PAGE 63

SOFTWARE TYPE-ID’S - AN OVERVIEW

All devices, software zones, and Annunciator points must be programmed with appropriate software

type identification. Software type I.D.s allow the 1010/2020 to identify the type and determine

functionality of points in the system.

Note: The control panel will not permit the changing of a Software Type I.D. in one group to a

Software Type I.D. in another group. To accomplish this, the device must be reinstalled by using the

Full Point Programming option of the Main Programming Menu.

RECOMMENDED TYPE ID’S FOR COMMON APPLICATIONS

INPUT DEVICES Type ID Tracking

(Non-Latching)

Analog Photo Optical Detector PHOT

Analog Duct Probe Detector PHOD Yes

Ionisation Detector ION

Combination Detector (OMNI) CMBO

Analog Thermal THER

Conventional AZF Circuit SCON

Break Glass MON

Pressure Switch MON

Flow Switch SPSU Yes

Tamper Switch SUPR Yes

Door Switch NONA Yes

Airflow Switch (AS1668) NONA Yes

OUTPUT DEVICES Type ID Notes

Bell Output (Monitored) CON Select as Silenceable

General Alarm Output CMXC Map to software zone as required

General Fault N/A Take direct from CPU terminals 6=C,

7=NC, 8=N0

General Isolate N/A Take direct from CPU terminals 1=C,

2=NC, 3=N0

A/C Trip – Latching FRCM When used with SCS-8 Module

A/C Trip – Non-Latching FORC

Fan Start Relay FRCM

Fan Stop Relay FRCM

Relay Output FORC Map to software zone as required

Monitored Output CMXS Map to software zone as required

Mains Fail Relay Output ACFC
