ATOM 2.0 FULL LCD
Components:
a. Mode (M) Button
b. Select (S) Button
c. Light (L) Button
d. Advance (A) Button
e. LED Warning Light
f. Bar Graph
g. Icon - indicates O2BG
h. Icon - Ascend Arrow
i. Symbol - STOP TIME
DIVE TIME
j. Symbol - NITROX (Mode)
k. Symbol - FT or M (Depth)
l. Symbol - MAX
m. Icons - Tank 1, 2, 3
n. Symbol - FO2
o. Symbols - AIR TIME
TIME NDC
TIME O2
TIME TAT
TIME SURF
p. Icon - degrees (Temperature)
q. Icon - Daily Alarm, or -
Transmitter Link
r. Symbol - PSI or BAR (Pressure)
s. Icon - Descend Arrow
t. Icon - Low Battery
r
b
c
d
e
t
s
g
h
j
k
l
q
o
m
i
Pay special attention to items marked
with this Warning symbol.
p
a
f
n
