OVERALL DIMENSIONS
Chapter 2
sizes in mm
The height indicated (C-D) is to be understood with wheels, which increases the height by 6.5 cm.
The height indicated (C-D) is to be understood with feet, which increases the height by 6.5 cm.
Model A B C D
FX/201/M - FX/201/T -
F/202/M - FX/202/T - FXID/202/T
42,7 74 73,4 111,9
FX/301/T - FX/302/T 42,7 74 73,4 111,9
RB/301/T - RB/302/T 47,8 80,9 80,7 119
FX/401/T - FX/402/T - FXID/402/T 47,8 80,9 77,8 119
RB/401/T - RB/402/T - RBID/402/T 47,8 80,9 80,7 119
FX/601/T - FX/602/T - FXID/602/T 58,5 99 100,5 149
