Parallel Setup
Item Value Description
Parallel Enable
Disable
Enables/Disables the Centronics
interface.
Bi-Direction Enable
Disable
Enables/Disables the bi-directional
Centronics interface.
ECP Enable
Disable
Enables/Disables the ECP mode.
Ack Width Narrow
Medium
Wide
Sets the ACK width for compatible
reception.
Narrow = 0.5µs
Medium = 1.0µs
Wide = 3.0µs
Ack/Busy
Timing
Ack in Busy
Ack while Busy
Sets the order to output the BUSY
signal and ACK signal for compatible
reception.
I-Prime 3 microseconds
50 microseconds
Disable
Sets the time to enable/disable the
I-PRIME signal.
Offline Receive Enable
Disable
Enables/disables a function that
maintains the receive-possible state
without changing an interface signal
even though an alarm occurs. When
this is set to Enable, the interface
keeps the receive-possible state even
when you press the Off-line operating
panel switch. The interface sends the
BUSY signal only when the reception
buffer is full or a service call occurs.
This menu is not displayed on a Non-
PS machine.
