1.2 Structure of MFP
The insides of multi function printers are composed of the following parts.
• Scanner part
• Electronic photography process part
• Paper path
• Control part (CU part/PU part)
• Power supply parts (high voltage part/low voltage part)
Figure 1-2 shows the composition of the MFP.
Figure 1-2
