4.REPLACEMENT OF PARTS
4.2.12 Duplex Belt Assy
(1) Take out the Frame-Assy-TR. (Refer to 4.2.11)
(2) Remove the cassette and set the printer unit on its right side.
(3) Remove the E-ring (RE4-SK)
and slide the Shaft-Dup-Clutch in the direction of
the arrow.
(4) Remove the screw (Silver)
and Frame-Duplex-Assy .
(5) Remove the four pieces of Bearing
, Roller-Feed-Duplex and Duplex-Belt .
(6) Installing is performed by the inverse procedure with removing.
Shaft-Dup-Clutch
①
④
⑤
③
④
⑥
4.2.13 DC Motor
(1) Remove the Cover Side (R). (Refer to 4.2.2)
(2) Remove the screw (Silver)
, and remove FG-Cable .
(3) Remove four screws (Silver)
, and remove PlateShield (CU) .
①
②
L
AN
ACC
View A
View A View B
View B
③
④
③
③
④
④
View A
View A View B
To Next Page
