Conventions Used in This Manual
Model Notations
“E5CSV and E5CS-U” or “E5CSV/E5CS-U” are used when the information being provided
applies to all E5CSV and E5CS-U Digital Temperature Controllers.
Meanings of Abbreviations
The following abbreviations are used in parameter names, figures and in text explanations. These
abbreviations mean the following:
Symbol Term
PV
Process value
SP
Set point
AT
Auto-tuning
ST
Self-tuning
EU
Engineering unit
(See note.)
Note:
“EU” stands for Engineering Unit. EU is used as the minimum unit for engineering units such as °C, m,
and g. The size of EU varies according to the input type.
For example, when the input temperature setting range is –99 to +1300°C, 1 EU is 1°C, and when the
input temperature setting range is –0.0 to +199.9°C, 1 EU is 0.1°C.
How to Read Display Symbols
The following tables show the correspondence between the symbols displayed on the displays and
alphabet characters.
a b c d e f g h i j k l m
A B C D E F G H I J K L M
n o p q r s t u V w x y z
N O P Q R S T U V W X Y Z
