Omron E5CSV User Manual

4-3
Operations for
Applications
4.2 Assigning Outputs
•
• By changing the control output assignment, alarm output 1
assignment, and alarm output 2 assignment settings, the functions
assigned to each output can be changed in the initial setting level
(3).
• The following functions can be assigned to each output.
■ Output
Assignment
*1. Not displayed for models without alarm outputs.
*2. Not displayed for models without alarm output 2.
Parameter name Symbol Setting Initial status
Control output
assignment
ot
1: Control
function
Alarm 1
assignment *1
a1
2: Alarm 1
function
Alarm 2
assignment *2
a2
0: Not assigned
1: Control
function
2: Alarm 1
function
3: Alarm 2
function
3: Alarm 2
function
4.2 Assigning Outputs

Omron E5CSV Specifications

General

Setting Method	Digital setting using front panel keys
Dimensions	48 x 48 x 78 mm (W x H x D)
Number of Control Outputs	1
Control Method	ON/OFF control or PID control
Input Types	Thermocouple
Supply Voltage	100 to 240 VAC
Output Type	Relay or Voltage (for driving SSR)
Display	7-segment digital display
Mounting Method	Panel mounting
Setting Resolution	0.1 °C or 1 °C
Power Supply Voltage	100 to 240 VAC
Ambient Operating Humidity	25% to 85% RH
Ambient Operating Temperature	-10 to 55°C (with no icing or condensation)
