Omron E5CSV User Manual

4-9
Operations for
Applications
● Parameters Related to Alarm Delays
Parameter name Setting
Set (monitor)
values
Alarm 1 ON Delay
Initial setting level (4)
SP mode
0 to 999 (s)
Alarm 2 ON Delay
Initial setting level (5)
SP mode
0 to 999 (s)
Alarm 1 OFF Delay
Initial setting level (4)
ALM mode
0 to 999 (s)
Alarm 2 OFF Delay
Initial setting level (5)
ALM mode
0 to 999 (s)
* The defaults are 0, i.e., the ON and OFF delays are disabled.
Operating Procedure
Use the following procedure to set ON and OFF delays for the alarm
1 function.
An ON delay of 5 s and an OFF delay of 10 s will be set.
1. Select the initial setting level (4).
2. Select the “alarm 1 ON delay” (SP mode) parameter by pressing
the M key.
3. Press the U and D Keys to set the parameter to 5.
4. Press the M key to select the “alarm 1 OFF delay” (ALM mode)
parameter.
5. Press the U and D Keys to set the parameter to 10.
M
M
Initial settin
g
level
(
4
)
SP mode
・Alarm 1 ON delay
ALM mode
・Alarm 1 OFF delay
0
SP ALM ALM 1 2
OUT
0
1 2 ALM ALM SP
OUT
- 4 -
1 2 ALM ALM SP
OUT
5
SP ALM ALM 1 2
OUT
0
1 2 ALM ALM SP
OUT
1
U/D
U/D
4.5 Alarm Delays

Omron E5CSV Specifications

General

Setting Method	Digital setting using front panel keys
Dimensions	48 x 48 x 78 mm (W x H x D)
Number of Control Outputs	1
Control Method	ON/OFF control or PID control
Input Types	Thermocouple
Supply Voltage	100 to 240 VAC
Output Type	Relay or Voltage (for driving SSR)
Display	7-segment digital display
Mounting Method	Panel mounting
Setting Resolution	0.1 °C or 1 °C
Power Supply Voltage	100 to 240 VAC
Ambient Operating Humidity	25% to 85% RH
Ambient Operating Temperature	-10 to 55°C (with no icing or condensation)
