Section 3 Basic Operations
3-2
Basic
Operations
3.1 Setting the Input Type
The E5CS is available in models with thermocouple input, models with platinum resistance
thermometer input, thermistor input, and multi-input (thermocouple/platinum resistance thermometer)
models. The type of Sensor that can be used depends on the model. Confirm the model that was
purchased, and set the Sensor to be used and the temperature range switch.
■ Input Type
● Thermocouple
● Platinum
Resistance Thermometer
Specifications
Temper-
ature
range
Input temperature range
0 0 to 200
(°C)
/ 0 to 200
(°F)
1 0 to 300
(°C)
/ 0 to 300
(°F)
2 0 to 400
(°C)
/ 0 to 400
(°F)
3 0 to 500
(°C)
/ 0 to 500
(°F)
4 0 to 600
(°C)
/ 0 to 600
(°F)
K
5 0 to 999
(°C)
/ 0 to 999
(°F)
6 0 to 200
(°C)
/ 0 to 999
(°F)
7 0 to 300
(°C)
/ 0 to 300
(°F)
8 0 to 400
(°C)
/ 0 to 400
(°F)
J/L
9 0 to 500
(°C)
/ 0 to 500
(°F)
• The default is 2.
• The control range is –10% to 10% FS for each temperature range.
• J/L can be selected using the control mode switch 5. J is set when the
switch is OFF, and L is set when the switch is ON.
Specifications
Temper-
ature
range
Input temperature range
0 -50 to 50
(°C)
/ -50 to 50
(°F)
1 0.0 to 50.0
(°C)
/ 0.0 to 50.0
(°F)
2 -20 to 80
(°C)
/ -20 to 80
(°F)
3 0.0 to 99.9
(°C)
/ 0.0 to 99.9
(°F)
4 0 to 200
(°C)
/ 0 to 200
(°F)
5 0 to 300
(°C)
/ 0 to 300
(°F)
6 0 to 400
(°C)
/ 0 to 400
(°F)
7 0 to 300
(°C)
/ 0 to 600
(°F)
8 0 to 400
(°C)
/ 0 to 800
(°F)
JPt100/Pt100
9 0.0 to 199.9
(°C)
/ 0.0 to 199.9
(°F)
• The default is 3.
• The control range is –10% to 10% FS for each temperature range.
• JPt100/Pt100 can be selected using the control mode switch 5.
JPt100 is set when this switch is OFF, and Pt100 is set when this
switch is ON.
• If unit is changed to 1 degree when the SP and alarm value for the
temperature range are displayed in 0.1-units from 0.0 to 199.9, 0.0 to
99.9 or 0.0 to 50.0, the values will be multiplied by 10 (e.g., 0.5
becomes 5). If the unit is changed in the reverse direction, the values
will be divided by 10. After changing the range, reset the Controller.
