Omron E5CSV User Manual

4-1
Section 4 Operations
for
Applications
•
•
•
4.1 Moving to the Initial Setting Level ......................................4-2
4.2
Assigning Outputs .............................................................4-3
■ Output Assignment .................................................... 4-3
4.3 Alarm Functions ................................................................4-4
■ Alarm Hysteresis .......................................................4-4
■ Standby Sequence ....................................................4-4
■ Alarm Latch ...............................................................4-4
● Alarm Latch Clear Operation ..............................4-4
■ Close in Alarm/Open in Alarm ...................................4-5
● Summary of Alarm Operation ............................. 4-5
4.4 Setting the SP Upper and Lower Limit Values ....................4-6
■ Set Point Limiter......................................................... 4-6
■ Setting .......................................................................4-6
4.5 Alarm Delays .....................................................................4-8
■ Alarm Delays ............................................................. 4-8
● Operation of Alarm ON and OFF Delays (for an
Upper-limit Alarm) ..................................................4-8
● Parameters Related to Alarm Delays .................. 4-9

Omron E5CSV Specifications

General

Setting Method	Digital setting using front panel keys
Dimensions	48 x 48 x 78 mm (W x H x D)
Number of Control Outputs	1
Control Method	ON/OFF control or PID control
Input Types	Thermocouple
Supply Voltage	100 to 240 VAC
Output Type	Relay or Voltage (for driving SSR)
Display	7-segment digital display
Mounting Method	Panel mounting
Setting Resolution	0.1 °C or 1 °C
Power Supply Voltage	100 to 240 VAC
Ambient Operating Humidity	25% to 85% RH
Ambient Operating Temperature	-10 to 55°C (with no icing or condensation)
