Omron E5CSV User Manual

3.1 Setting the Input Type
3-3
Basic
Operations
● Thermistor
● Multi-input (Thermocouple/Platinum Resistance Thermometer) Models
Control Mode Switch 5:
OFF
Control Mode Switch 5:
ON
Specifications
Temper-
ature
range
Input temperature range
6 KΩ (0°C)
0 -50 to 50
(°C)
/ -50 to 100
(°F)
6 KΩ (0°C)
1 0 to 100
(°C)
/ 0 to 200
(°F)
30 KΩ (0°C)
2 50 to 150
(°C)
/ 100 to 300
(°F)
550 Ω (200°C)
3 100 to 200
(°C)
/ 200 to 400
(°F)
4 KΩ (200°C)
4 150 to 300
(°C)
/ 300 to 600
(°F)
6 KΩ (0°C)
5 -50 to 50
(°C)
/ -50 to 100
(°F)
6 KΩ (0°C)
6 0 to 100
(°C)
/ 0 to 200
(°F)
30 KΩ (0°C)
7 50 to 150
(°C)
/ 100 to 300
(°F)
550 Ω (200°C)
8 100 to 200
(°C)
/ 200 to 400
(°F)
THE
4 KΩ (200°C)
9 150 to 300
(°C)
/ 300 to 600
(°F)
• The default is 1. If the setting is changed to a temperature range that goes
below 0°C, the minimum value inside the SP range will be automatically used
as the SP. The SP will be displayed when the power is turned ON.
• The control range depends on the setting numbers, as follows:
Input setting numbers 0 and 5: −50 to +60°C
Input setting numbers 2 and 7: 0 to 160°C or 35 to 320°F
Input setting numbers 3 and 8: 0 to 210°C or 35 to 420°F
Input setting numbers 4 and 9: 25 to 315°C or 80 to 630°F
Others: −10% to 10% FS
Specifications
Temper-
ature
range
Input temperature range
0 -99 to 1300
(°C)
/ -99 to 1999
(°F)
K
1 0.0 to 199.9
(°C)
/ 0.0 to 199.9
(°F)
2 -99 to 850
(°C)
/ -99 to 1500
(°F)
J
3 0.0 to 199.9
(°C)
/ 0.0 to 199.9
(°F)
L 4 -99 to 850
(°C)
/ -99 to 1500
(°F)
5 -99 to 400
(°C)
/ -99 to 700
(°F)
T
6 0.0 to 199.9
(°C)
/ 0.0 to 199.9
(°F)
U 7 -99 to 400
(°C)
/ -99 to 700
(°F)
N 8 -99 to 1300
(°C)
/ -99 to 1999
(°F)
R 9 0 to 1700
(°C)
/ 0 to 1999
(°F)
Specifications
Temper-
ature
range
Input temperature range
0 -99 to 850
(°C)
/ -99 to 1500
(°F)
1 0.0 to 199.9
(°C)
/ 0.0 to 199.9
(°F)
2 -99 to 99
(°C)
/ -99 to 99
(°F)
3 0 to 200
(°C)
/ 0 to 200
(°F)
Pt100
4 0 to 400
(°C)
/ 0 to 400
(°F)
5 -99 to 500
(°C)
/ -99 to 900
(°F)
6 0.0 to 199.9
(°C)
/ 0.0 to 199.9
(°F)
7 -99 to 99
(°C)
/ -99 to 99
(°F)
8 0 to 200
(°C)
/ 0 to 200
(°F)
JPt100
9 0 to 400
(°C)
/ 0 to 400
(°F)
• The default is 0.
• The control range is ±20°C or ±40°F of the input temperature range.
• If unit is changed to 1 degree when the SP and alarm value for the
temperature range are displayed in 0.1-units from 0.0 to 199.9, 0.0 to
99.9 or 0.0 to 50.0, the values will be multiplied by 10 (e.g., 0.5
becomes 5). If the unit is changed in the reverse direction, the values
will be divided by 10. After changing the range, reset the Controller.

Omron E5CSV Specifications

General

Setting Method	Digital setting using front panel keys
Dimensions	48 x 48 x 78 mm (W x H x D)
Number of Control Outputs	1
Control Method	ON/OFF control or PID control
Input Types	Thermocouple
Supply Voltage	100 to 240 VAC
Output Type	Relay or Voltage (for driving SSR)
Display	7-segment digital display
Mounting Method	Panel mounting
Setting Resolution	0.1 °C or 1 °C
Power Supply Voltage	100 to 240 VAC
Ambient Operating Humidity	25% to 85% RH
Ambient Operating Temperature	-10 to 55°C (with no icing or condensation)
