Omron E5CSV User Manual

5.6 Initial Setting Level (3)
5-17
Parameters
SP mode
SP upper limit
• This parameter sets the upper limit of the set point. The set point can be set
within the range with the upper limit set in the “SP upper limit” parameter. If
this parameter is reset, however, any set point that is outside of the new
range will be forcibly changed to the SP upper limit.
• When the input type and temperature unit have been changed, the set point
upper limit is forcibly changed to the upper limits of the Sensor.
• The decimal point position depends on the selected Sensor.
Input type Setting range Unit Default
Thermocouple 400
Platinum resistance
thermometer
99.9
Thermistor 100
Multi-input
(thermocouple/platinum
resistance thermometer)
models
SP lower limit +1 to
Input range upper limit
EU
1300
ALM mode
SP lower limit
• This parameter sets the lower limit of the set point. The set point can be set
within the range with the lower limit set in the “SP lower limit” parameter. If
this parameter is reset, however, any set point that is outside of the new
range will be forcibly changed to the SP lower limit.
• When the input type and temperature unit have been changed, the set point
lower limit is forcibly changed to the lower limits of the Sensor.
• The decimal point position depends on the selected Sensor.
Input type Setting range Unit Default
Thermocouple 0
Platinum resistance
thermometer
0.0
Thermistor 0
Multi-input
(thermocouple/platinum
resistance thermometer)
models
Input range lower limit to
SP upper limit −1
EU
−99
Function
Setting
Function
Setting

Omron E5CSV Specifications

General

Setting Method	Digital setting using front panel keys
Dimensions	48 x 48 x 78 mm (W x H x D)
Number of Control Outputs	1
Control Method	ON/OFF control or PID control
Input Types	Thermocouple
Supply Voltage	100 to 240 VAC
Output Type	Relay or Voltage (for driving SSR)
Display	7-segment digital display
Mounting Method	Panel mounting
Setting Resolution	0.1 °C or 1 °C
Power Supply Voltage	100 to 240 VAC
Ambient Operating Humidity	25% to 85% RH
Ambient Operating Temperature	-10 to 55°C (with no icing or condensation)
