Omron E5CSV User Manual

Section 5 Parameters
5-12
Parameters
ALM mode
Integral time setting unit
Hysteresis width
Temperature width in which the ■ deviation
indicator lights
• Select the integral time setting unit.
• Set the hysteresis width.
• Set the temperature width in which the ■ deviation indicator lights.
• Set the integral time setting unit either to seconds or minutes in the initial
setting level (2).
• The hysteresis width enables stable operation at the ON/OFF switching point
for ON/OFF control. The default setting is 0.1% FS for multi-input
(thermocouple/platinum resistance thermometer) models, and 0.2% FS for
other input types.
• The default setting for the temperature width in which the ■ deviation
indicator lights is ±0.25% FS for multi-input (thermocouple/platinum
resistance thermometer) models, and ±1% FS for other input types.
100’s digit 10’s digit 1’s digit
Displayed
number
Integral time
setting unit
Hysteresis width
(ON/OFF control)
Temperature width
in which ■
deviation indicator
lights
O Second 0% FS 0% FS
1 Minute 0.05% FS ±0.1% FS
2 0.1% FS ±0.25% FS
3 0.2% FS ±0.5% FS
4 0.3% FS ±0.75% FS
5 0.5% FS ±1% FS
6 0.75% FS ±1.25% FS
7 1% FS ±1.5% FS
8 1.5% FS ±1.75% FS
9 2% FS ±2% FS
Function
Setting

Omron E5CSV Specifications

General

Setting Method	Digital setting using front panel keys
Dimensions	48 x 48 x 78 mm (W x H x D)
Number of Control Outputs	1
Control Method	ON/OFF control or PID control
Input Types	Thermocouple
Supply Voltage	100 to 240 VAC
Output Type	Relay or Voltage (for driving SSR)
Display	7-segment digital display
Mounting Method	Panel mounting
Setting Resolution	0.1 °C or 1 °C
Power Supply Voltage	100 to 240 VAC
Ambient Operating Humidity	25% to 85% RH
Ambient Operating Temperature	-10 to 55°C (with no icing or condensation)
