Omron E5CSV User Manual

3.7 Determining PID Constants (AT, ST, Manual Setup)
3-11
Basic
Operations
● ST Stable Range
Operating Procedure
The ST stable range determines the set value under which ST
(self-tuning) functions operate.
This procedure sets the ST stable range to 20°C.
1. Press the M Key from the initial setting level (1) and select “ST
stable range” (IS mode).
2. Use the U and D Keys to set the parameter to 20°C.
ALM mode
IS mode
M
M
M
5 1
1 2 ALM ALM SP
OUT
Initial settin
g
level
(
1
)
SP mode
- 1 -
1 2 ALM ALM SP
OUT
0
1 2 ALM ALM SP
OUT
5 3
1 2 ALM ALM SP
OUT
0
2
1 2 ALM ALM SP
OUT
U/D
・ST stable
range

Omron E5CSV Specifications

General

Setting Method	Digital setting using front panel keys
Dimensions	48 x 48 x 78 mm (W x H x D)
Number of Control Outputs	1
Control Method	ON/OFF control or PID control
Input Types	Thermocouple
Supply Voltage	100 to 240 VAC
Output Type	Relay or Voltage (for driving SSR)
Display	7-segment digital display
Mounting Method	Panel mounting
Setting Resolution	0.1 °C or 1 °C
Power Supply Voltage	100 to 240 VAC
Ambient Operating Humidity	25% to 85% RH
Ambient Operating Temperature	-10 to 55°C (with no icing or condensation)
