Side-mounting bracket for environment-resistant case
Series connection cable for environment-resistant case
Top/bottom mounting bracket (for top/bottom mounting)
Side flat mounting bracket (4 brackets per set)
Appearance Model name Note
F39-EJ-S 2 brackets per set
Appearance Model name Note
For emitter F39-JJR3WE-L Required for series connection with an
environment-resistant case. Series-connection
cable for 1 set of sensors.
For receiver F39-JJR3WE-D
Appearance Model name Application Note
F39-LJ1
(Standard brackets included
with the F3SJ)
Purchase replacements when
damaged or lost.
2 brackets for emitter, 2
brackets for receiver (4 brackets
per set)
Appearance Model name Application Note
F39-LJ2
Use these small-sized brackets
when performing side mounting
with top/bottom mounting
brackets, so that they do not
protrude from the detection
surface.
2 brackets for emitter, 2
brackets for receiver (4 brackets
per set)
(Use in combination with top/
bottom mounting brackets)
