Omron K3HB-H User Manual

Functions and Operations
5.27 Compensating Forced-zero References
5-71
Parameter Setting Procedure
A Press the L [LEVEL] Key for at least
3 s in RUN level to move to the initial
setting level.
3 s min.
•“L 0 ” is displayed on the level/bank
display to indicate the initial setting
level.
B Press the M [MODE] Key several times
to change the PV display to “amov.”
•
This parameter is not displayed for the
initial status due to setting level protect.
Refer to "Limiting Key Operations" (P.5-
102) for information on removing setting
level protect.
C Press the S [SHIFT] Key to make the
SV display flash.
• The setting can be changed when the
SV display starts to flash.
D Use the U [UP] and S [SHIFT] Keys
to set the password “-0169.” Press the
M [MODE] Key to move to the
advanced function setting level.
•“
L f” is displayed on the level/bank
display to indicate the advanced
function setting level.
E Press the M [MODE] Key several times
to switch the PV display to “z-trm.”
F Press the S [SHIFT] Key to make the
SV display flash.
• The setting can be changed when the
SV display starts to flash.
G Use the U [UP] Key to change the set
value to “on.”
• Change the set value to “off” to turn
OFF zero-trimming.
H Press the M [MODE] Key to switch to
the next parameter.
• The set value is registered.
I Press the L [LEVEL] Key for at least
1 s to return to the initial setting level.
1 s min.
L
cal
0
Displays “L 0.”
L 0
M
amov
0
L 0
S
amov
00000
L 0
SU
M
init
Displays “L f.”
off
L f
M
z-trm
off
L f
S
z-trm
off
L f
U
z-trm
on
L f
M
hp-f
off
L f
L
L 0
