Omron K3HB-H User Manual

Functions and Operations
Section 5 Functions and Operations
5-78
5.30 Changing Normal Display Values to Maximum
and Minimum Values
The PV display value displayed after power is turned ON, after the
RESET input, immediately after moving to RUN level, and immediately
after automatic display return to RUN or adjustment levels can be set
to either the present value, maximum value, or minimum value.
The display value selection is set using the following parameter.
Parameter Setting Procedure
Display adjustment level
Parameter Set value Meaning of set value
Display value selection
disp
pv Present value
max Max. value
min Min. value
A Press the L [LEVEL] Key for at least
3 s in RUN level to move to the initial
setting level.
3 s min.
• “ L 0 ” is displayed on the level/bank
display to indicate the initial setting level.
B Press the L [LEVEL] Key several
times to move to the display adjustment
level.
•
“ L 2” is displayed on the level/bank display
to indicate the display adjustment level.
C Press the M [MODE] Key to change
the PV display to “disp.”
D Press the S [SHIFT] Key to make the
SV display flash.
• The setting can be changed when the
SV display starts to flash.
E Use the U [UP] Key to change the set
value.
F Press the M [MODE] Key to switch to
the next parameter.
• The set value is registered.
G Press the L [LEVEL] Key for at least
1 s to return to RUN level.
1 s min.
X V S H
disp
L 2
(DISP)
L
Displays “L 0.”
L 0
L
sv. dsp
off
Displays “L 2."
L 2
M
disp
pv
L 2
S
disp
pv
L 2
U
disp
max
L 2
M
ret
10
L 2
L
123. 4
123. 4
