Omron K3HB-H User Manual

Functions and Operations
5.38 Using Comparative Set Value Banks
5-93
5.38 Using Comparative Set Value Banks
The K3HB has 8 banks where groups of comparative set values can be set beforehand. Comparative set
values can be changed easily by switching these banks. This function is called “bank selection.”
Comparative set values HH, H, L, and LL are set in groups to banks. Comparative set values can be set to
all 8 banks, numbered 0 to 7. Banks can be selected using front panel keys or an event input.
* If the bank copy function is used, the comparative set values set to one bank can be copied to all banks.
■ 1. Specifying the Bank Selection Method
Before banks can be selected, the bank selection method must be
specified. The bank selection function is enabled when the selection
method is specified. The individual bank settings cannot be made until
bank selection is enabled.
The bank selection method is set using the following parameter.
*1. With this setting, banks cannot be selected using event inputs.
*2. With this setting, banks cannot be selected using key operations.
Event inputs can be used only for models with connectors.
The relationship between event input (BANK1, BANK2, and
BANK4) ON/OFF status and the bank number is shown below.
Explanation of Functions Bank selection
Advanced function setting level/Comparative set value level
X V S H
Parameter Set value Meaning of set value
Bank selection
bnk-c
off Bank selection disabled
key Bank selection using keys
(*1)
ev Bank selection
using event input (*2)
Bank No.
External terminals
BANK1 BANK2 BANK4
0
OFF OFF OFF
1ON
OFF OFF
2
OFF ON OFF
3ONON
OFF
4
OFF OFF ON
5ON
OFF ON
6
OFF ON ON
7ONONON
bnk-c
L f
(BNK-C)
Applicable models:
K3HB-@@@
+
K35-2
K35-4
