Omron K3HB Applications Manual

Functions and Operations
5.12 Changing Comparative Output Patterns
5-37
Parameter Setting Procedure
Preventing output chattering → P.5-38
Delaying output OFF timing → P.5-44
Outputting at set intervals → P.5-41
Reversing output logic → P.5-51
Holding already output comparative outputs → P.5-47
Performing output tests → P.5-71
Allocating other outputs to PASS output → P.5-49
A Press the L[LEVEL] Key for at least 3
s in RUN level to move to the initial
setting level.
3 s min.
•"
L
0" is displayed on the level/bank
display to indicate the initial setting
level.
B Press the M[MODE] Key several times
to change the PV display to "out-p".
C Press the S[SHIFT] Key to make the
SV display flash.
• The setting can be changed and the
SV display starts to flash.
D Use the U[UP] Key to change the set
value.
E Press the M[MODE] Key to switch to
the next parameter.
• The set value is registered.
F Press the L[LEVEL] Key for at least 1
s to return to RUN level.
1 s min.
L
cal
0
Displays "
L
0".
L 0
M
out-p
nomal
L
0
S
out-p
nomal
L
0
U
out-p
zone
L
0
M
cal
0
L
0
L
123. 4
123. 4
Remarks

Omron K3HB Specifications

General

Input Type	Thermocouple, RTD, Voltage, Current
Control Output	Relay, Voltage, Current
Communication	RS-485
Mounting	Panel
Humidity	25% to 85%
Supply Voltage	100-240 VAC, 24 VDC
