Omron K3HB Applications Manual

Functions and Operations
Section 5 Functions and Operations
5-12
5.3 Setting Scaling Values
Set scaling to convert and display input values as any value. Inputs A
and B are set separately.
One point *
<Setting parameter for input A>
<Setting parameter for input B>
The decimal point position for scaling input values depends on the
input type.
Initial setting level
* Use the teaching function to use actual inputs to set scaling input values "inp.
a1", "inp. a2", "inp.
b1", and "inp.
b2".
Refer to Teaching (P.5-15) for details.
Parameter Set value Meaning of set value
Scaling input value A1
inp.
a1
-19999 to
99999 *
Input value corresponding
to dsp. a1
Scaling display value A1
dsp.
a1
-19999 to
99999
Display value
corresponding to inp.
a1
Scaling input value A2
inp.
a2
-19999 to
99999 *
Input value corresponding
to dsp. a2
Scaling display value A2
dsp.
a2
-19999 to
99999
Display value
corresponding to inp.
a2
Parameter Set value Meaning of set value
Scaling input value B1
inp.b1
-19999 to
99999 *
Input value corresponding
to dsp.b1
Scaling display value B1
dsp.b1
-19999 to
99999
Display value
corresponding to inp.b1
Scaling input value B2
inp.b2
-19999 to
99999 *
Input value corresponding
to dsp.b2
Scaling display value B2
dsp.b2
-19999 to
99999
Display value
corresponding to inp.b2
Input type Set value
0.000 to 20.000 mA 0.
000 to 20. 000
4.000 to 20.000 mA 4.
000 to 20. 000
0.000 to 5.000 V 0.
000 to 5. 000
1.000 to 5.000 V 1.
000 to 5. 000
±5.000 V -5.
000 to 5. 000
±10.000 V -10.
000 to 10. 000
k
L 0
(K)
dsp. b2
L
0
(DSP.B2)
inp. a1
L 0
(INP.A1)
dp
L 0
(DP)
dsp. b1
L 0
(DSP.B1)
dsp. a2
L 0
(DSP.A2)
dsp. a1
L 0
(DSP.A1)
inp. b2
L 0
(INP.B2)
inp. b1
L 0
(INP.B1)
inp. a2
L 0
(INP.A2)

Omron K3HB Specifications

General

Input Type	Thermocouple, RTD, Voltage, Current
Control Output	Relay, Voltage, Current
Communication	RS-485
Mounting	Panel
Humidity	25% to 85%
Supply Voltage	100-240 VAC, 24 VDC
