Omron K3HB Applications Manual

Appendices
Parameter list
A-9
Comparative
set value
display
L
4
Comparative set value bank
s?.bnk 0 to 70
Comparative set value 0HH
s?0.hh -19999 to 99999 99999
Comparative set value 0H
s?0.h -19999 to 99999 99999
Comparative set value 0L
s?0.l -19999 to 99999 -19999
Comparative set value 0LL
s?0.ll -19999 to 99999 -19999
Comparative set value 1HH
s?1.hh -19999 to 99999 99999
Comparative set value 1H
s?1.h -19999 to 99999 99999
Comparative set value 1L
s?1.l -19999 to 99999 -19999
Comparative set value 1LL
s?1.ll -19999 to 99999 -19999
Comparative set value 2HH
s?2.hh -19999 to 99999 99999
Comparative set value 2H
s?2.h -19999 to 99999 99999
Comparative set value 2L
s?2.l -19999 to 99999 -19999
Comparative set value 2LL
s?2.ll -19999 to 99999 -19999
Comparative set value 3HH
s?3.hh -19999 to 99999 99999
Comparative set value 3H
s?3.h -19999 to 99999 99999
Comparative set value 3L
s?3.l -19999 to 99999 -19999
Comparative set value 3LL
s?3.ll -19999 to 99999 -19999
Comparative set value 4HH
s?4.hh -19999 to 99999 99999
Comparative set value 4H
s?4.h -19999 to 99999 99999
Comparative set value 4L
s?4.l -19999 to 99999 -19999
Comparative set value 4LL
s?4.ll -19999 to 99999 -19999
Comparative set value 5HH
s?5.hh -19999 to 99999 99999
Comparative set value 5H
s?5.h -19999 to 99999 99999
Comparative set value 5L
s?5.l -19999 to 99999 -19999
Comparative set value 5LL
s?5.ll -19999 to 99999 -19999
Comparative set value 6HH
s?6.hh -19999 to 99999 99999
Comparative set value 6H
s?6.h -19999 to 99999 99999
Comparative set value 6L
s?6.l -19999 to 99999 -19999
Comparative set value 6LL
s?6.ll -19999 to 99999 -19999
Comparative set value 7HH
s?7.hh -19999 to 99999 99999
Comparative set value 7H
s?7.h -19999 to 99999 99999
Comparative set value 7L
s?7.l -19999 to 99999 -19999
Comparative set value 7LL
s?7.ll -19999 to 99999 -19999
Bank copy copy off, on off
Output test
L
t
Test input test off, -19,999 to
99999
off
Level Parameter name Display Setting range Initial
value
Unit Set
value
