Omron K3HB Applications Manual

Appendices
Appendices
A-8
Input
adjustment
L
1
Timing hold tmg-h nomal, s-h, p-h,
b-h, p-p
nomal
ON timing delay on-t 0 to 4999 0 ms
OFF timing delay off-t 0 to 4999 0 ms
Zero-limit z-lim off, on off
Zero limit value lim-p 0 to 99 0
Step value step off, 2, 5, 10 off
Average type a?g-t smpl, mo?e smpl
Averaging times a?g-n 1, 2, 4, 8, 16, 32, 64,
128, 256, 512, 1024
1
Display
adjustment
L
2
Comparative set value
display
s?.dsp off, on off
Display refresh period d.ref off, *5, 1, 2, 4 off s
Display color selection color grn-r, grn, red-g,
red
grn-r
Display value selection disp p?, max, min p?
Automatic display return ret 0 to 99 10 s
Position meter type pos-t off, inc, inc-r,
de?, de?-r
inc
Position meter upper limit
pos-h -19999 to 99999 99999
Position meter lower limit pos-l -19999 to 99999 -19999
Level Parameter name Display Setting range Initial
value
Unit Set
value

Omron K3HB Specifications

General

Input Type	Thermocouple, RTD, Voltage, Current
Control Output	Relay, Voltage, Current
Communication	RS-485
Mounting	Panel
Humidity	25% to 85%
Supply Voltage	100-240 VAC, 24 VDC
