Omron K3HB Applications Manual

Functions and Operations
Section 5 Functions and Operations
5-50
E Press the M[MODE] Key to change the
PV display to "pass".
F Press the S[SHIFT] Key to make the
SV display flash.
• The setting can be changed when the
SV display starts to flash.
G Use the U[UP] Key to change the set
value.
H Press the M[MODE] Key to switch to
the next parameter.
• The set value is registered.
I Press the L[LEVEL] Key for at least 1
s to return to the initial setting level.
1 s min.
J Press the L[LEVEL] Key for at least 1
s to return to RUN level.
1 s min.
M
pass
pass
L
f
S
pass
pass
L
f
U
pass
h
L
f
M
hys
1
L
f
L
cal
0
L
0
L
123. 4
123. 4

Omron K3HB Specifications

General

Input Type	Thermocouple, RTD, Voltage, Current
Control Output	Relay, Voltage, Current
Communication	RS-485
Mounting	Panel
Humidity	25% to 85%
Supply Voltage	100-240 VAC, 24 VDC
