Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Brake resistance connection (P(+), DB)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-AB001 - 0.1 2.0 2.0 2.0 0.3 - - - -
- 3G3M1-AB001 0.2 - - - - 2.0 2.0 2.0 0.2
3G3M1-AB002 - 2.0 2.0 2.0 0.4 - - - -
- 3G3M1-AB002 0.4 - - - - 2.0 2.0 2.0 0.4
3G3M1-AB004 - 2.0 2.0 2.0 0.5 - - - -
- 3G3M1-AB004 0.55 - - - - 2.0 2.0 2.0 0.6
3G3M1-AB007 - 0.75 2.0 2.0 2.0 0.7 - - - -
- 3G3M1-AB007 1.1 - - - - 2.0 2.0 2.0 1.1
3G3M1-AB015 - 1.5 2.0 2.0 2.0 1.4 - - - -
- 3G3M1-AB015 2.2 - - - - 2.0 2.0 2.0 1.5
3G3M1-AB022 - 2.0 2.0 2.0 1.7 - - - -
- 3G3M1-AB022 3 - - - - 2.0 2.0 2.0 1.9
3G3M1-AB037 - 3.7 2.0 2.0 2.0 2.4 - - - -
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire
size [mm2]
Inverter ground (G)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
60°C 75°C 90°C
3G3M1-AB001 - 0.1 2.0 2.0 2.0
- 3G3M1-AB001 0.2 2.0 2.0 2.0
3G3M1-AB002 - 2.0 2.0 2.0
- 3G3M1-AB002 0.4 2.0 2.0 2.0
3G3M1-AB004 - 2.0 2.0 2.0
- 3G3M1-AB004 0.55 2.0 2.0 2.0
3G3M1-AB007 - 0.75 2.0 2.0 2.0
- 3G3M1-AB007 1.1 2.0 2.0 2.0
3G3M1-AB015 - 1.5 2.0 2.0 2.0
- 3G3M1-AB015 2.2 2.0 2.0 2.0
3G3M1-AB022 - 2.0 2.0 2.0
- 3G3M1-AB022 3 2.0 2.0 2.0
3G3M1-AB037 - 3.7 3.5 3.5 3.5
Note 1: At an allowable temperature of 60°C, use 600 V IV insulated wire, at 75°C 600 V HIV insulated
wire, and at 90°C 600 V crosslinked polyethylene insulated wire.
Note 2:
When the recommended wire size is 38 mm
2
, use crimped terminal model No. 38-6 made by
J.S.T. Mfg. Co., Ltd. or an equivalent product (*1 in table).
2 Design
2-40
M1 Series Standard Type User's Manual (I669)
