Omron M1 Series User Manual

Name: Omron M1 Series
Brand: Omron
Rating: 4 (1 reviews)

808 pages

To Next Page

To Previous Page

Power

supply

voltage

Standard appli-

cable motor (kW)

Inverter model

HHD/HD/HND/N

D mode

Semiconductor protection fuse

product number, manufacturer:

Mersen / Bussmann (Eaton)

Single-

phase 200

0.1 3G3M1-AB001 HHD PC30UD69V50□/170M3458

0.2 3G3M1-AB001

HND

3G3M1-AB002 HHD PC30UD69V50□/170M3458

0.4 3G3M1-AB002 HND

3G3M1-AB004 HHD PC30UD69V50□/170M3458

0.75 3G3M1-AB004 HND

3G3M1-AB007 HHD PC30UD69V50□/170M3460

1.1 3G3M1-AB007 HND

1.5 3G3M1-AB015 HHD PC30UD69V125□/170M3462

2.2 3G3M1-AB015 HND

3G3M1-AB022 HHD PC30UD69V125□/170M3463

3 3G3M1-AB022 HND

3.7 3G3M1-AB037 HHD PC30UD69V160□/170M3464

2 Design

2-84

M1 Series Standard Type User's Manual (I669)

Questions and Answers:

Need help?

Do you have a question about the Omron M1 Series and is the answer not in the manual?

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
